Positive & Negative pressure membrane press machine can be used to paste high glossy, PVC film and veneer on the surface of MDF, wood, plywood, wood-plastics and so on.
The specification:
Worktable size | 3000×1280mm |
Total power | 57.2Kw |
Negative/Vacuum pressure | -0.08Mpa |
Positive pressure | 0.4Mpa-0.5 Mpa |
Max. Working temperature | 180℃ |
Heating type | Oil heating (up) Electric &aluminum (down) High heat electric heating tube (air heating) |
Dia. And No. Of cylinder | 180mm *6 |
Control system | PLC touch screen |
PVC cutting system | Two sets |
Silicon membrane | Imported from Korea |
Overall dimensions | 11500×2250×2050mm |
Weight | 12000kg |
Main feature:
1. Advanced pneumatic hydraulic sealing system can make sure that this equipment can be operated in safe, stable and efficient way.
2. It has imported famous-brand vacuum pump and advanced pressure preparation heating device.
3. Automatic cooling system can ensure high quality products.
4. Automatic double aluminum alloy working table can double the working efficiency.
5. Advanced man-machine interface and large scale of PLC control can ensure the high level of automation and easy operation.
Working sample for cold glue profile wrapping machine
Product details:
1. Control system: PLC, touch screen control.
There are four modes of operation: high-glossy mode, PVC film mode, veneer mode and membrane mode. In addition, it can be set 50 Data, up to 50 different products and will be saved into memory. So when you change products, you can select the data very fast. It greatly facilitates the convenience of operation and the continuty of working process.
2. Pressure
There are different pressure modes, such as: positive pressure in the upper zone, positive pressure in the middle zone, negative pressure in the middle zone, and negative pressure in the lower zone, which can be changed up to different materials and process requirements. Positive pressure in the middle zone can reduce the use of silicon membrane, the loss of silicon membrane and production costs.
3. Famous brand vacuum pump and advanced backup pressure heating system ensure high quality of products.
4. Fully automatic double sided aluminum working plate, advanced PLC and touch screen control sytem greatly improve the automation operation.
Positive & Negative pressure membrane press machine can greatly improve the automation operation and work efficiency, ensuring high quality of products.
